Compact Power

At the heart of all innovations developed jointly by Linde eMotion and partners are: drive and pump motors, servo drives, and cycloidal gearboxes from the extremely reliable range of mass production technology used in forklift trucks from Linde Material Handling. Combined with an inverter,they can easily be incorporated into a wide range of applications as a drive to guarantee efficient performance without any emissions.

Electric Motors

Models at a Glance

Linde eMotion currently offers four motor models taken from Linde Material Handling series production, with each offering a different level of performance. The models are: IEC90, IEC112, IEC132 and IEC160. These are all available as either drive or pump motors.

Download Data Sheet

1 / 8

Design Features

Asynchronous motors for different voltages
Built-in rotational speed and temperature sensors
Standard package sizes

Key Figures for Electric Motors

Model	Use	Battery voltage [VDC]	Nominal capacity [kW]	Nominal rotational speed [rpm]	Nominal mode of operation
IEC90	Drive motor	24 48	1.2 2.6	2720 2480	S2 – 60 min S2 – 20 min
IEC112	Drive motor	24 48	5 8.5 10	2200 2150 2600	S2 – 45 min S3 – 15% S2 – 45 min
IEC132	Drive motor	80	16.3 17	2600 3190	S3 – 20% S3 – 15%
IEC160	Drive motor	80	25	2660 2700	S3 – 15% S3 – 20%
IEC112	Pump motor	48	9	2150	S3 – 15%
IEC132	Pump motor	80	17	3190	S3 – 15%
IEC160	Pump motor	80	25	2660	S3 – 20%

Servo Drives and Cycloidal Gearboxes

Servo drives and cycloidal gearboxes from Linde Material Handling are incredibly robust, and they are made up of perfectly aligned components. They are ideally suited to steer-by-wire applications based on a single component, and they boast a large rotational speed and torque range.
